Upload your Floor Plans
Send us your floor plan and we'll do the rest. Our team will look over your layout and put together a tailored underfloor heating design and itemised quote, with the right pipe, manifolds, controls and fittings for the job.
Whether it's a single room, a whole house or a multi-plot development, just upload your drawings below and we'll get back to you as soon as it's ready.
What to include
- Your floor plan or architect's drawings (PDF, JPG, PNG or DWG)
- Room dimensions, if they're not shown on the plan
- Floor construction for each area, e.g. screed, suspended timber or overlay
- Heat source, e.g. heat pump, gas boiler or not decided yet
- Floor finishes, if known (tiles, carpet, engineered wood)
- Any rooms you want left out
What you'll get back
- A pipe layout and zoning plan
- A full materials list with trade pricing
- Advice on controls and manifold positioning
- A heat loss calculation, if you need one
Don't have everything?
Send what you've got. A rough sketch with measurements is enough to get started, and we'll get in touch if we need anything else.
